Részletek
Adatok
Részletek
Manufacturer |
DVC |
---|---|
Technology |
IP video |
Compression |
H.264, H.264+, H.265, H.265+ |
Processor |
MStar SSR621Q |
Number of cameras |
16 |
HDD |
1 x SATA (1 x 10 TB max.) |
HDMI output |
Yes |
VGA output |
Yes |
Max resolution |
6Mpx |
Recording 6Mpx |
6Mpx@25fps |
Recording 5Mpx |
5Mpx@25fps |
Recording 4Mpx |
4Mpx@25fps |
Recording 3Mpx |
3Mpx@25fps |
Recording 2Mpx |
2Mpx@25fps |
Input bandwidth |
64Mbps |
Transmission bandwidth |
64Mbps |
Supported IP camera manufacturers |
DVC, Dahua, Hikvision |
Audio |
16 (from IP camera) |
Alarm output |
No |
RS485 |
No |
LAN |
10/100 Mbps RJ-45 |
Dual stream |
Yes |
DVR control |
Web browser, mouse |
Network access |
IE, NVMS2.0 |
Mobile access |
Android, iOS |
Power supply |
12V DC |
Consumption |
<5W without HDD |
Fan |
No |
Dimensions |
255 x 222 x 42 mm |
Operating temperature |
-10°C – 50°C |
Operating humidity |
10% – 90% |
Adatok
Gyártó
DVC
Technológia
IP
Csatornák száma
16
Raktárkészlet
1 db
Cikkszám
00001784
Státusz
ÚJ
