Részletek
| Manufacturer |
DVC |
|---|---|
| Technology |
HD video |
| Compression |
H.264, H.265 |
| Processor |
Novatek |
| Number of cameras |
16 analogue (AHD/TVI/CVI) + 8 IP |
| AHD to IP channels |
8 |
| HDD |
2 x SATA (2 x 8 TB max.) |
| HDMI output |
HDMI 2K/4K |
| VGA output |
1920 x 1080 |
| BNC output |
Yes |
| Spot output |
BNC |
| Max resolution |
8Mpx |
| Recording 8Mpx |
8Mpx@6fps |
| Recording 5Mpx |
5Mpx@12fps |
| Recording 5Mpx Lite |
5Mpx LITE@20fps |
| Recording 4Mpx |
4Mpx@12fps |
| Recording 4Mpx Lite |
4Mpx LITE@25fps |
| Recording 3Mpx |
3Mpx@12fps |
| Recording 2Mpx |
2Mpx@25fps |
| Recording 1Mpx |
1Mpx@25fps |
| Recording WD1 |
WD1@25fps |
| Recording IP |
8Mpx, 5Mpx, 4Mpx, 3Mpx, 2Mpx@25fps |
| Output bandwidth |
96Mbps |
| Input bandwidth |
32Mbps |
| Supported IP camera manufacturers |
DVC IP |
| Video analytics |
HD + IP kamere |
| Audio |
1 x out |
| Alarm inputs / outputs |
No |
| Alarm output |
No |
| RS485 |
Yes |
| LAN |
10/100/1000 Mbps RJ-45 |
| Dual stream |
Yes |
| DVR control |
Web browser, mouse |
| Network access |
IE, NVMS1000 |
| Mobile access |
Android, iOS |
| Power supply |
12V DC |
| Consumption |
<30W without HDD |
| Fan |
Yes |
| Dimensions |
380 x 268 x 52 mm |
| Operating temperature |
-10°C – 50°C |
| Operating humidity |
10% – 90% |
Adatok
Gyártó
DVC
Technológia
IP + AHD / HD-CVI / HD-TVI /CVBS
Felbontás
8 Mpx
Csatornák száma
16
Raktárkészlet
0 db
Cikkszám
00001447
Státusz
ÚJ
