Részletek
Adatok
Részletek
Manufacturer |
DVC |
---|---|
Technology |
HD video |
Compression |
H.265 |
Processor |
Novatek |
Number of cameras |
4 analogue (AHD/TVI/CVI) + 2 IP |
HDD |
1 x SATA (1 x 8 TB max.) |
HDMI output |
Yes |
VGA output |
1920 x 1080 |
BNC output |
No |
Spot output |
No |
Max resolution |
1080p LITE |
Recording 2Mpx LITE |
2Mpx LITE@25fps |
Recording IP |
2Mpx@25fps |
Max. IP camera bit rate |
4Mbps/per channel |
Supported IP camera manufacturers |
DVC IP |
Audio |
1 x out |
Alarm inputs / outputs |
No |
Alarm output |
No |
RS485 |
No |
LAN |
10/100 Mbps RJ-45 |
Dual stream |
Yes |
DVR control |
Web browser, mouse |
Network access |
IE, NVMS2.0 |
Mobile access |
Android, iOS |
Power supply |
12V DC |
Consumption |
<5W without HDD |
Fan |
No |
Dimensions |
255 x 222 x 42 mm |
Operating temperature |
-10°C – 50°C |
Operating humidity |
10% – 90% |
Channel number |
4 |
Adatok
Gyártó
DVC
Technológia
IP + AHD / HD-CVI / HD-TVI /CVBS
Felbontás
1080p LITE
Csatornák száma
4
Raktárkészlet
1 db
Cikkszám
00001510
