Részletek
Adatok
Részletek
Manufacturer |
DVC |
---|---|
Technology |
IP video |
Optical sensor |
1/3'' SmartSens SC430AI |
DSP |
Novatek NT98513 |
Resolution |
4Mpx, 3Mpx, 2Mpx@25fps |
Bit rate |
64Kbps – 8Mbps |
Compression |
H.264, H.264+, H.265, H.265+ |
Housing |
Turret |
Lens |
2.8 – 12mm moto-zoom |
Minimum illumination (Lux) |
0.03 lux@F1.6 |
Horizontal angle |
96° – 32.33° |
Onvif |
Yes |
Video analytics |
AI: Line crossing, object tracking, space intrusion, people counting, crowd density, facial recognition, exceptions |
SD card |
Up to 256Gb |
Audio |
No |
IR |
30-40m |
Number of IR LED |
2 x Array Black glass IR LED |
Day / night function |
ICR |
Dynamic range |
True WDR 120 dB |
HLC |
Yes |
BLC |
Yes |
Noise reduction |
2D/3D DNR |
3-Axis |
Yes |
Antivandal housing |
Yes |
IP protection |
IP66 |
IK protection |
IK10 |
Power supply |
12V DC, PoE |
Consumption |
<12W |
Operating temperature |
-30°C – 60°C |
Dimensions |
Ø 111.5 x 99.6 mm |
Adatok
Gyártó
DVC
Objektív típusa
Varifokális MotoZoom
Technológia
IP
Felbontás
4 Mpx
Kivitel
Dome
Tokozás típusa
Kötődoboz kompatibilitás:
- H1- DAJ-33, DAJ-41, DAM-35
- H2- DAJ-38, DAJ-40, DAM-35
- H3- DAJ-38, DAJ-40, DAM-35
- H4- DAJ-38, DAJ-40, DAM-35
- H5- DAJ-42, DAM-35
- H6- DAJ-39, DAM-35
- H7- DAJ-44, DAM-32, DAM-34, DAM-35
- H8- DAJ-33, DAJ-38, DAJ-40, DAM-32, DAM-35
- H9- DAJ-33, DAJ-38, DAJ-40, DAM-35
H7 - közepes turret
LED Típus
FEHÉR LED
EXTREME Dark Technológia
Igen
SD Kártya
Igen
Mikrofon
Igen
Analitika
Meta Ai
Raktárkészlet
3 db
Cikkszám
00001534
Státusz
ÚJ
