DCN-TF4282N 4Mpx/20fps, fix objektív 2.8 mm, H.265, IR LED hatótávolság 10-20 m,
Részletek
Adatok
Részletek
Manufacturer |
DVC |
---|---|
Technology |
IP video |
Optical sensor |
1/3'' Smartsens SC401AI |
Resolution |
4Mpx@20fps/3Mpx, 2Mpx, 1Mpx@25fps |
Bit rate |
64Kbps – 5Mbps |
Compression |
H.265 |
Housing |
Turret |
Lens |
2.8mm |
Minimum illumination (Lux) |
0.011 lux@F1.2 |
Horizontal angle |
109.7° |
Onvif |
Yes |
Video analytics |
Crossing the line, following the object, trespassing, exceptions |
SD card |
No |
Audio |
Built-in microphone |
IR |
10-20m |
Number of IR LED |
1 x Array Black glass IR LED |
Day / night function |
ICR |
Dynamic range |
D-WDR |
HLC |
Yes |
BLC |
Yes |
Noise reduction |
3D DNR |
3-Axis |
Yes |
Antivandal housing |
No |
IP protection |
IP67 |
IK protection |
No |
Power supply |
12V DC, PoE |
Consumption |
<4W |
Operating temperature |
-20°C – 55°C |
Dimensions |
Ø 94.8 x 82.8 mm |
Lens type |
2.8 mm |
Adatok
Gyártó
DVC
Objektív típusa
Fix objektív
Technológia
IP
Felbontás
4 Mpx
Kivitel
Dome
Tokozás típusa
Kötődoboz kompatibilitás:
- H1- DAJ-33, DAJ-41, DAM-35
- H2- DAJ-38, DAJ-40, DAM-35
- H3- DAJ-38, DAJ-40, DAM-35
- H4- DAJ-38, DAJ-40, DAM-35
- H5- DAJ-42, DAM-35
- H6- DAJ-39, DAM-35
- H7- DAJ-44, DAM-32, DAM-34, DAM-35
- H8- DAJ-33, DAJ-38, DAJ-40, DAM-32, DAM-35
- H9- DAJ-33, DAJ-38, DAJ-40, DAM-35
H9 - Mini műanyag turret
LED Típus
IR LED
EXTREME Dark Technológia
Nem
SD Kártya
Nem
Mikrofon
Igen
Analitika
VCA
Raktárkészlet
0 db
Cikkszám
00000486
